36” x 130’ Pit Portable Radial Stacker (Light Duty Grain Only)
PIT PORTABLE RADIAL STACKER
LIGHT DUTY GRAIN ONLY
36” x 130’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Low profile tail, (Approximately 42”)
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive
Lagged head 18” Dia., 7 7/16” Shaft & Ball Bearing
14" Plain Drum Tail, 2 15/16” Shaft & Ball Bearings w/ Screw Take-ups
World Wide /WSMR6-9 Drive, Motor Mount, Belt Guard
30 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, 2 Ply, Chevron V-Cleat
8'-0” Receiving Hopper w Skirt Rubber, extended sides
Pivot Plate, Tow Hook, weight box (weight not included)
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
AVAILABLE OPTIONS
POWER TRAVEL
BACKSTOP
SECOND AXLE(Lateral or Parallel)(16”Tires)
SECOND AXLE(LateralorParallel)(20”Tires)*
*THIS AXLE IS REQUIRED IF SECOND POWER TRAVEL IS SPECIFIED
24” x 120’ Radial Stacker
RADIAL STACKER
24” x 120’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 20” Tires & Rims
Lagged head 18” Dia., 3 7/16” Shaft & ROLLER Bearing
Mid type wrap drive with snub roller
Winged Tail, 2 15/16” Roller Bearings w/Screw Take-ups
World Wide #6 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
30” x 120’ Pit Portable Radial Stacker (Light Duty Only)
PIT PORTABLE RADIAL STACKER
LIGHT DUTY ONLY
30” x 120’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Low profile tail, (Approximately 42”)
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive
Lagged head 18” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide /WW #6-15 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, 2 Ply, 220 PIW, 3/16 x 1/16 cover
48” Receiving Hopper w Skirt Rubber, extended sides
Pivot Plate, Tow Hook, weight box (weight not included)
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 120’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
36” x 120’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Low profile tail, (Approximately 42”)
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive- 16” Snub - 3 7/16” Shaft & Roller Bearing
Lagged head 18” Dia., 3 7/16” Shaft & Roller Bearing
14” Winged Tail, 3 7/16” Shaft & Roller Bearings w/Screw Take-ups
World Wide /WW #6-15 Drive, Motor Mount, Belt Guard
30 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, 2 Ply, 220 PIW, 3/16 x 1/16 cover
48” Receiving Hopper w Skirt Rubber, extended sides
Pivot Plate, Tow Hook, weight box (weight not included)
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 120’ Pit Portable Radial Stacker (Light Duty Grain Only)
PIT PORTABLE RADIAL STACKER
LIGHT DUTY GRAIN ONLY
36” x 120’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Low profile tail, (Approximately 42”)
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive
Lagged head 18” Dia., 3 7/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide /WSMR #6-9/1 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, 2 Ply, 220 PIW, Chevron V-Cleat
48” Receiving Hopper w Skirt Rubber, extended sides
Pivot Plate, Tow Hook, weight box (weight not included)
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
AVAILABLE OPTIONS
POWER TRAVEL
BACKSTOP
SECOND AXLE(Lateral or Parallel)(16”Tires)
SECOND AXLE(LateralorParallel)(20”Tires)*
*THIS AXLE IS REQUIRED IF SECOND POWER TRAVEL IS SPECIFIED
24” x 110’ Radial Stacker
RADIAL STACKER
24” x 110’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 20” Tires & Rims
Lagged head 18” Dia., 3 7/16” Shaft & Roller Bearing
Mid type wrap drive with snub roller – 2 15/16 Shaft & Roller Bearings
Winged Tail, 2 15/16” Roller Bearings w/Screw Take-ups
World Wide #6 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
30” x 110’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
30” x 110’
36” Deep Truss, 3x4x 5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive with snub
Lagged head 18” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #5 Drive, Motor Mount, Belt Guard
20 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
24” x 100’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
24” x 100’
36” Deep Truss, 3x4x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Lagged head 16” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
WORLD Wide #5 Drive, Motor Mount, Belt Guard
20 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
30” x 100’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
30” x 100’
36” Deep Truss, 3x4x 5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive with snub
Lagged head 18” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #6 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 100’Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
36” x 100’
36” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive
Lagged head 18” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #6 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
42” x 100’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
42” x 100’
36” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive with snub
Lagged head 18” Dia., 3 7/16” Shaft & Roller Bearing
Winged Tail, 3 7/16” Shaft & Roller Bearings w/Screw Take-ups
World Wide #6 Drive, Motor Mount, Belt Guard
30 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
48” x 100’ Pit Portable Radial Stacker(Light Duty Only)
PIT PORTABLE STACKER
LIGHT DUTY ONLY
48” x 100’
48” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, Heavy Duty Axle, 20” Tires & Rims
Lagged head 18” Dia., 3 7/16” Shaft & Roller Bearings
Mid Type Wrap Drive – 16” Snub 3 7/16 Shaft & Roller Bearings
Winged Tail,14”, 3 7/16” Shaft & Roller Bearings w/Screw Take-ups
World Wide #6 Drive, Mid Wrap type drive
30 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 36” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
Not intended for materials greater than 50 lbs/ft3
24” x 80’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
24” x 80’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 20” Tires & Rims
Lagged head 16” Dia., 2 7/16” Shaft & Ball Bearing
Winged Tail, 2 7/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #4 Drive, Motor Mount, Belt Guard
15 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
30” x 80’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
30” x 80’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 20” Tires & Rims
Lagged head 16” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #5 Drive, Motor Mount, Belt Guard
20 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Swivel Pivot plate
Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 80’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
36” x 80’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 20” Tires & Rims
Lagged head 16” Dia., 2 15/16” Shaft & Ball Bearing
Winged Tail, 2 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #5 Drive, Motor Mount, Belt Guard
20 hp, TEFC, 1800 RPM
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w /Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
42” x 80’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
42” x 80’
36” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 10x10 Tubing Axle, 20” Tires & Rims
Wrap type mid drive with snub
Lagged head 16” Dia., 3 7/16” Shaft & Roller Bearing
Winged Tail, 2 15/16” Shaft & Roller Bearings w/Screw Take-ups
World Wide #6 Drive, Motor Mount, Belt Guard
25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
48” x 80’ Pit Portable Radial Stacker (Standard Duty)
PIT PORTABLE RADIAL STACKER
STANDARD DUTY
48” x 80’
36” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, Heavy Duty Axle, 20” Tires & Rims
Lagged head 16” Dia., 3 7/16” Shaft & Roller Bearings
Winged Tail, 14, 3 7/16” Shaft & Roller Bearings w/Screw Take-ups
World Wide, Shaft mount #6 Drive
30 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
|
18” x 60’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
18” x 60’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #3 Drive, Motor Mount, Belt Guard
7.5 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 4” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 4” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
24” x 60’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
24” x 60’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #3 Drive, Motor Mount, Belt Guard
7.5 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
30” x 60’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
30” x 60’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 7/16” Shaft & Ball Bearing
Winged Tail, 2 7/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #4 Drive, Motor Mount, Belt Guard
10 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 60’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
36” x 60’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Dual Tires & Rims
Lagged head 16” Dia., 2 7/16” Shaft & Ball Bearing
Winged Tail, 2 7/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #4 Drive, Motor Mount, Belt Guard
15 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
42” x 60’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
42” x 60’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 20” Tires & Rims
Lagged head 16” Dia., 3 7/16” Shaft & Jones Roller Bearing
14” Winged Tail, 3 7/16” Shaft & Jones Roller Bearings w/Screw Take-ups
World Wide #6-25 Drive, Motor Mount, Belt Guard
North American Electric - 25 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 3 Ply, 330 PIW, 1/4 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
48” x 60’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
48” x 60’
36” Deep Truss, 3x4x5/16 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, Heavy Duty Axle, 20” Tires & Rims
Lagged head 20” Dia., 3 7/16” Shaft & Roller Bearing
Winged Tail,14”, 3 7/16” Shaft & Roller Bearings w/Screw Take-ups
World Wide #6-25 Drive, motor mount
30 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate at tail
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
24” x 50’ Pit Portable (OFF ROAD) Radial Stacker
PORTABLE (OFF ROAD) RADIAL STACKER
24” x 50’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 14”, 2 3/16” Shaft & Ball Bearings w/ Take-ups
WORLD WIDE #3 drive, Motor mount, and guard
Motor, 5 hp, TEFC, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pintail Tow Hook
Tail Guard
Primed & Painted
30” x 50’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
30” x 50’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #3 Drive, Motor Mount, Belt Guard
7.5 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 50’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
36” x 50’
36” Deep Truss, 3x3x1/4 Cord Angle, 2x2x1/4 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #3 Drive, Motor Mount, Belt Guard
7.5 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
18” x 40’ Portable (Off Road) Stacker
PORTABLE (OFF ROAD) STACKER
18” x 40’
24” Deep Truss, 2x2x1/4 Cord Angle, 11/2x11/2x3/16 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 1 15/16” Shaft & Ball Bearing
Winged Tail, 1 15/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #2, Motor mount, and guard
Motor, 3 hp, TEFC, 230/460 volt
Pioneer, 4” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 4” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pintail Tow Hook
Tail Guard
Primed & Painted
24” x 40’ Portable (Off Road) Radial Stacker
PORTABLE (OFF ROAD)RADIAL STACKER
24” x 40’
24” Deep Truss, 2x2x1/4 Cord Angle, 11/2x11/2x3/16 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
WORLD WIDE #3, Motor mount, and guard
Motor, 5 hp, TEFC, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pintail Tow Hook
Tail Guard
Primed & Painted
30” x 40’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
30” x 40’
24” Deep Truss, 2x2x1/4 Cord Angle,11/2x11/2x3/16 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #3 Drive, Motor Mount, Belt Guard
7.5 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
36” x 40’ Pit Portable Radial Stacker
PIT PORTABLE RADIAL STACKER
36” x 40’
24” Deep Truss, 2x2x1/4 Cord Angle, 11/2x11/2x3/16 Lattice
Heavy Duty Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 2 3/16” Shaft & Ball Bearing
Winged Tail, 2 3/16” Shaft & Ball Bearings w/Screw Take-ups
World Wide #3 Drive, Motor Mount, Belt Guard
7.5 hp, TEFC, 1800 RPM, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pivot Plate, Tow Hook
Tail Guard
Primed & Painted, Tool Steel Gray, Unless Specified Differently
24” x 20’ Portable (Off Road) Radial Stacker
PORTABLE (OFF ROAD) RADIAL STACKER
24” x 20’
24” Deep Truss, 2x2x1/4 Cord Angle, 11/2x11/2x3/16 Lattice
Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 1 15/16” Shaft & Ball Bearing
Winged Tail, 1 15/16” Shaft & Ball Bearings w/Screw Take-ups
WORLD WIDE #2, Motor mount, and guard
Motor, 3 hp, TEFC, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pintail Tow Hook
Tail Guard
Primed & Painted
30” x 20’ Portable (Off Road) Stacker
PORTABLE (OFF ROAD) STACKER
30” x 20’
24” Deep Truss, 2x2x1/4 Cord Angle, 11/2x11/2x3/16 Lattice
Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 1 15/16” Shaft & Ball Bearing
Winged Tail, 1 15/16” Shaft & Ball Bearings w/Screw Take-ups
WORLD WIDE #2, Motor mount, and guard
Motor, 3 hp, TEFC, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pintail Tow Hook
Tail Guard
Primed & Painted
36” x 20’ Portable (Off Road) Stacker
PORTABLE (OFF ROAD) STACKER
36” x 20’
24” Deep Truss, 2x2x1/4 Cord Angle, 11/2x11/2x3/16 Lattice
Undercarriage, 8x8 Tubing Axle, 16” Tires & Rims
Lagged head 16” Dia., 1 15/16” Shaft & Ball Bearing
Winged Tail, 1 15/16” Shaft & Ball Bearings w/Screw Take-ups
WORLD WIDE #2, Motor mount, and guard
Motor, 3 hp, TEFC, 230/460 volt
Pioneer, 5” x 35 deg., CEMA C Top Rollers on 48” Centers
Pioneer, 5” Returns w/Brackets, 10’ Centers
Belt, Rubber, 2 Ply, 220 PIW, 3/16 x 1/16 Cover
48” Load Zone w/Skirt Rubber
Pintail Tow Hook
Tail Guard
Primed & Painted
|
|
